KOYO BEARING

K9X12X13FH KOYO NEEDLE ROLLER BEARINGS

KOYO Radial needle roller and cage assemblies have a steel cage that provides both inward and outward retention for the needle rollers. The designs provide maximum cage strength consistent with the inherent high load-ratings of needle roller bearings. Accurate guidance of the needle rollers by the cage bars allows for operation at high speeds. Needle roller and cage assemblies have either one or two rows of needle rollers.

Get A Quote
Contact Us

KOYO NEEDLE ROLLER BEARINGS. SINGLE-ROW, DOUBLE-ROW ASSEMBLIES.

Various part numbers in stock, welcome inquiry. Fast shipment within 2-3 working days.

Load Ratings
Shaft Fw Ew Assembly Dynamic Static
Dia. Designation C C0
mm mm mm kN
in in in lbf
8 8 11 K8X11X13H 5.22 5.78
0.315 0.315 0.4331 1170 1300
9 9 12 K9X12X10FH 4.27 4.6
0.3543 0.3543 0.4724 960 1030
9 12 K9X12X10FV 4.27 4.6
0.3543 0.4724 960 1030
9 12 K9X12X13FH 5.57 6.47
0.3543 0.4724 1250 1450
9 12 K9X12X13FV 5.57 6.47
0.3543 0.4724 1250 1450
9 13 K9X13X8H 3.96 3.5
0.3543 0.5118 890 787
10 10 13 K10X13X10H 5.4 6.43
0.3937 0.3937 0.5118 1210 1450
10 13 K10X13X10TN 4.29 4.77
0.3937 0.5118 964 1070
10 13 K10X13X13 5.9 7.16
0.3937 0.5118 1330 1610
10 13 K10X13X16 7.43 9.64
0.3937 0.5118 1670 2170
10 14 K10X14X10H 6.12 6.29
0.3937 0.5512 1380 1410
10 14 K10X14X13H 7.88 8.71
0.3937 0.5512 1770 1960
10 16 K10X16X12F 8.39 7.47
0.3937 0.6299 1890 1680
10 16 K10X16X12TN 7.5 6.4
0.3937 0.6299 1690 1440
12 12 15 K12X15X10H 5.85 7.51
0.4724 0.4724 0.5906 1320 1690
12 15 K12X15X13H 6.78 9.03
0.4724 0.5906 1520 2030
12 16 K12X16X13H 7.49 8.51
0.4724 0.6299 1680 1910

WHCD Bearing Co.,Ltd is professional bearing supplier, engaged in bearing business with more than eighteen years, export to worldwide countries, as America, European, Middle-East, Southeast Asia …etc. with plenty long-term cooperation customers. WHCD Bearing company will provide professional and prompt solution for customers.Original Quality and Warranted, and Bearing experts team support customer service. Various bearing types for customer choose:

Bearing Types:
Self-aligning ball bearing
Cylindrical roller bearing
Spherical roller bearing
Tapered roller bearing
Angular contact ball
Needle roller
Deep groove ball bearing
Axial deep groove ball
Pillow block bearing and units
LM/Linear Guide
